T2100-48mm John Crane Seals(48x64x30mm)|Type 2100 Elastomer Bellows Seal for Shaft Size 48
Product Details:
| Place of Origin: |
CHINA |
| Brand Name: |
TLANMP |
| Certification: |
ISO 9001:2005 |
| Model Number: |
T2100-48mm |
Payment & Shipping Terms:
| Minimum Order Quantity: |
1 |
| Price: |
$1~$500 |
| Packaging Details: |
Industrial neutral packaging (Paper Box) |
| Delivery Time: |
1-3 day after Payment |
| Payment Terms: |
T/T,WU,Paypal,Alipay etc |
| Supply Ability: |
1~1000 pieces per month |
Contact Now
Detailed Product Description
| Standard Or Nonstandard: |
Standard |
Style: |
Mechanical Seal |
| Material: |
Silicone |
|
T2100-48mm John Crane Seals(48x64x30mm)|Type 2100 Elastomer Bellows Seal for Shaft Size 48mm Pumps (Material:SiC/Carbon) |
|
Series |
John Crane Seals Type 2100 |
|
Model Number |
T2100-48mm |
|
Shaft Size |
48mm |
|
Introduction |
TYPE 2100 Fully Unitized, Heavy-duty Elastomer Bellows Shaft Seal:
Designed for demanding applications, the Type 2100 mechanical seal is a compact, unitized, single-spring elastomer bellows seal that offers maximum durability and performance.
Ideal for use in centrifugal, rotary and turbine pumps, compressors, chillers and other rotary equipment
The Type 2100 is often found in water-based applications, such as wastewater treatment, potable water, HVAC, pool and spa and other general applications.
|
Application
Date |
John Crane Type 2100
1.Equivalent to:John Crane Type 2100,AES Seal B05,Flowserve Pac-Seal 140,Sterling 540
Operating range
• Shaft diameter: d1 = 10 … 100 mm
• Pressure: Up to 20 bar (290 PSI),
• Temperature: t = -20 °C … +200 °C
• Sliding velocity: vg = 15 m/s (3000 fpm)
• Admissible axial movement: ±2.0 mm
|
